01
LUXION Double Touch Dimmer Switch
A compact, elegant and minimalist design. Enjoy the versatility of the new smart switches.
Luxion
Luxion Glass Touch Dimmer Light Switch – 2 Gang
SKU: LX-MT-D201G-W
AED 85
In stock
1
- Delivery across all seven emirates. Free on orders over AED 750.
- Order now, we confirm availability and delivery with you before you pay.
Luxion 2 gang touch dimmer light switch with a tempered glass panel, smartphone-precise touch sensor and minimalist design in four colours.
Product details
2 gang dimmer touch light switch with a glass panel by Luxion. The Luxion range of light switches stands out for its compact, elegant and minimalist design. They are versatile, and the touch sensor is highly precise, just like that of a smartphone. The structure is durable and the switches do not discolour over time. It is a practical product, made from quality materials and built to last, bringing functionality and comfort to your home.
Highlights
02
Adjust the Light with a Simple Touch
Use the switch to change the light intensity in your room. With a simple touch of the button, the lamp gradually changes its brightness.
- Left button: ON/OFF and light intensity for bulb 1
- Right button: ON/OFF and light intensity for bulb 2
03
Key Features
- Moisture resistant – can be used in damp environments
- Touch sensor – extremely precise, just like a smartphone sensor
- Does not discolour – the elegant design stays intact
04
Compatible Bulbs
- Dimmable LED: 300W max.
- Incandescent: 1000W max.
- Halogen: 1000W max.
- RGB smart bulbs: not compatible
05
Structure
- Elegant glass panel
- Switch module
- Metal frame
- Screw fixing system (60 mm spacing)
06
Dimensions
- Panel: 86 mm x 86 mm
- Panel thickness: 9 mm
- Module depth: 26 mm
- Module height: 49 mm
07
Technical Data
As printed on the module label (Capacitive Dimmer Touch Switch).
- Rated operational voltage: 110V ~ 240V AC
- Capability allowance: -15% ~ +10%
- Load power: 5-700W/gang, 700W in total
- Working temperature: -20°C ~ +70°C
- Relative humidity: 10% ~ 93% (non-condensing)
- Operating frequency: 50/60 Hz
- Energy consumption: 0.5W
- Life time: 100,000 times
- Markings: CE, FC, RoHS
08
Wiring Diagram
Connect live (L) to terminal L; the two lamps connect to terminals L1 and L2, with their other side to neutral (N). Cut off the power before installation and uninstallation.
- L: Live
- L1: Bulb 1
- L2: Bulb 2
- N: Neutral (to the lamps)
09
Installation Steps
- 1. Open the package.
- 2. Connect the wires and tighten the screws.
- 3. Use the 2 screws to fix the frame.
- 4. Fit the front panel (click into place).
