Momentary Touch Switch Module, 12/24V DC
A momentary (push-return) touch switch module designed for direct current circuits at 12/24V, suitable for mechanical doorbells.
Luxion
Luxion Glass Touch 1 Gang Momentary Switch – 12/24V DC
SKU: LX-MT-V101G-W
AED 80
In stock
1
- Delivery across all seven emirates. Free on orders over AED 750.
- Order now, we confirm availability and delivery with you before you pay.
Luxion 1 gang momentary (push-return) glass touch switch for 12/24V DC circuits, with a compact, minimalist design and a precise touch sensor.
Product details
Luxion 1 gang momentary (push-return) switch for 12/24V DC with a tempered glass touch panel. The Luxion range of switches stands out for its compact, elegant and minimalist design. The switches are versatile, and the touch sensor is highly precise, just like a smartphone screen. The construction is durable and the switches do not discolour over time. It is a practical product, made from quality materials and built to last, bringing convenience and comfort to your home.
Highlights
02
Technical Data
- Power supply: 12V - 24V DC
- Maximum current: 10A
- Operating temperature: -20°C ~ +70°C
- Relative humidity: 10% ~ 90% (non-condensing)
- Tolerance: -15% ~ +10%
- Consumption: 0.2W
- Terminals: DC24-, L, L1, L2 (DC24+ on L)
- Markings: UKCA, RoHS, CE
03
Precise Touch Sensor
The touch sensor is extremely precise, just like the sensor in a smartphone.
04
Moisture Resistant
Can be used in humid environments.
05
Fade-Resistant Design
The colour does not fade, so the elegant design stays intact.
06
Installation
Warning: disconnect the power supply before installation.
- 1. Open the package.
- 2. Connect the wires and tighten the screws.
- 3. Use the 2 screws to fix the frame.
- 4. Fit the front panel (click into place).
