01
Touch Sensor
The touch sensor is extremely precise, just like the sensor on a smartphone.
Luxion
Luxion Glass Frame 1 Gang 2-Way / Intermediate Light Switch + Socket, Series A
SKU: LX-MT-A102/MP010-W
AED 107
In stock
1
- Delivery across all seven emirates. Free on orders over AED 750.
- Order now, we confirm availability and delivery with you before you pay.
Luxion Series A 1 gang 2-way/intermediate light switch with socket in a sleek glass frame, available in White, Black, Grey and Gold.
Product details
Luxion Series A 1 gang 2-way (staircase) / intermediate light switch + socket with a glass frame, featuring a compact, elegant and minimalist design. The structure is durable and the products do not discolour over time. It is a practical product, made from quality, long-lasting materials, bringing functionality and comfort to your home.
Highlights
02
Does Not Discolour
The elegant design stays intact over time.
03
Installation Steps
- 1. Open the package.
- 2. Connect the wires and tighten the screws.
- 3. Use the screws to secure the frame.
- 4. Fit the front panel (click into place).
04
Wiring Diagrams
The diagrams show two-way and intermediate (staircase) wiring on a ~220V supply using L, N and the L1, L2 and L4 terminals, with two or three switch modules controlling the same light or lights.
- Two switch modules controlling one light
- Three switch modules controlling one light
- Three switch modules controlling multiple lights
05
Technical Data (2-Way Switch Module)
- Power supply: 90V ~ 250V
- Load: 600W / channel – resistive
- Operating temperature: -20°C ~ +70°C
- Frequency: 50/60Hz
- Standby consumption: 0.02W
- Humidity: 10% ~ 93%
- Markings: UKCA, CE, RoHS
06
Safety Notice
Caution: switch off the mains power during installation or removal.
