Livolo USB Type-C Charging Socket with Glass Frame – White — image 4
1/4
Livolo

Livolo USB Type-C Charging Socket with Glass Frame

SKU: SH96060

AED 164

In stock

Colour: White
1
  • Delivery across all seven emirates. Free on orders over AED 750.
  • Order now, we confirm availability and delivery with you before you pay.

Livolo USB-C wall socket with glass frame, up to 45W fast charging for smartphones, tablets and laptops, in 4 colours.

Product details

The Livolo USB Type-C charging socket allows fast charging of the latest-generation devices. The maximum output power of the Livolo socket with USB-C port is 45W. Devices such as smartphones, tablets and laptops can be connected directly to the USB-C socket for faster charging. It is available in 4 colours: White, Black, Grey and Gold.

1. Supported charging protocols:
PD, QC, FCP, AFC, APPLE 5V/2.4A, BC1.2 DCP, etc.
2. Once a device is connected to the socket, it automatically selects the charging method supported by the device.

Highlights

Livolo USB Type-C Charging Socket with Glass Frame – Livolo 45W USB Type-C Socket
01

Livolo 45W USB Type-C Socket

A wide range of products with a simple design and an outstanding mechanism. This Livolo wall socket provides a 45W USB Type-C charging port.

  • USB Type-C port
  • 45W output (GaN marking on the module)
  • Available in several frame colours
Livolo USB Type-C Charging Socket with Glass Frame – Design and Materials
02

Design and Materials

The panel is made from high-quality glass that resists scratches and high temperatures. It does not discolour, so the elegant design stays intact.

  • High-quality glass panel
  • Scratch-resistant
  • Resistant to high temperatures
  • Does not discolour
Livolo USB Type-C Charging Socket with Glass Frame – Structure
03

Structure

  • Glass frame
  • Socket module
  • Metal frame
  • Screw fixing system
Livolo USB Type-C Charging Socket with Glass Frame – Dimensions
04

Dimensions

  • Frame: 80 mm x 80 mm
  • Screw fixing spacing: 60 mm
  • Panel thickness: 4 mm
  • Module depth: 33 mm
  • Side profile: 8 mm
Livolo USB Type-C Charging Socket with Glass Frame – Wiring Diagram
05

Wiring Diagram

Connect the neutral and live wires to the marked terminals.

  • Neutral (N): N/G terminal
  • Live (L): L (IN) terminal
Livolo USB Type-C Charging Socket with Glass Frame – Installation Steps
06

Installation Steps

  • 1. Open the package.
  • 2. Connect the wires and tighten the screws.
  • 3. Use the 2 screws to fix the frame.
  • 4. Fit the front panel (it clicks into place).
