Luxion Zigbee Touch Light Switch Module – 1 Gang (LX-ZT-101)
SKU: LX-ZT-101
AED 83
In stock
1
- Delivery across all seven emirates. Free on orders over AED 750.
- Order now, we confirm availability and delivery with you before you pay.
Luxion 1 gang Zigbee touch switch module for Luxion glass frames and panels, with Alexa and Google Home control via the Luxion Zigbee hub.
Product details
The Luxion 1 gang light switch module with Zigbee protocol can be mounted on its own on a Luxion panel, or together with other Luxion sockets and light switches on a Luxion glass frame.
Luxion light switches with Zigbee protocol work only together with the Luxion Zigbee hub. Through the hub, you can also control them using the Amazon Alexa or Google Home voice assistants.
Compatible only with Luxion glass frames and panels.
Highlights
02
Installation – Wiring Diagram
The module connects to the live (L) supply, with the lighting load wired to the L1 terminal and the neutral (N) going to the light fitting.
- L: live (phase) input
- L1: output to the light
- N: neutral connected to the light fitting
03
Two-Way and Multi-Way Wiring
The banners include wiring diagrams for two-way (stairway) control with two switches and multi-way (intermediate) control with three switches on a 220V circuit.
- Two-way diagram: 2 switch modules controlling one light
- Multi-way diagram: 3 switch modules controlling one light
04
Technical Data
- Power supply: 90 - 250V AC 50/60Hz
- Load power: 1000W/gang
- Compatible operating system: iOS/Android
- Wireless type: ZigBee 2.4 GHz
- Wireless standard: IEEE 802 15.4
- Working temperature: -20°C ~ 70°C
- Wireless consumption: <0.2W
- Working humidity: ≤95%
- Markings: CE, UKCA, FC, RoHS
05
Dimensions
Fixed in place with a screw mounting system.
- Screw mounting spacing: 60 mm
- Front: 50 mm x 50 mm
- Depth: 5 mm + 26 mm
- Body height: 49 mm
06
What's Not Included
This is the switch module only; the glass panel and metal frame are sold separately.
- Glass panel: not included
- Metal frame: not included
