Luxion Triple Touch Switch Module
A three-gang capacitive touch switch module from LUXION, designed to control three separate lighting circuits.
Luxion
Luxion 3 Gang Touch Light Switch Module – LX-MT-301
SKU: LX-MT-301
AED 79
In stock
1
- Delivery across all seven emirates. Free on orders over AED 750.
- Order now, we confirm availability and delivery with you before you pay.
Luxion 3 gang touch light switch module, designed to fit Luxion tempered glass panels and frames alongside other Luxion modules.
Product details
The Luxion 3 gang touch light switch module. It can be fitted on its own in a Luxion panel, or combined with other Luxion sockets and light switches in a Luxion glass frame.
Compatible only with Luxion glass frames and panels.
Highlights
02
Installation – Wiring Diagram
Connect the live (L) and neutral (N) supply as shown in the wiring diagram, with each light connected to its own output terminal. Cut off the power before installation and removal.
- L: Live (phase) input
- L1, L2, L3: Outputs to lights 1, 2 and 3
- N: Neutral connected to the lights
03
Technical Data
- Type: Capacitive 1 way Touch Switch
- Rated operational voltage: 110V ~ 240V AC
- Capability allowance: -15% ~ +10%
- Load power: 3-800W/gang, 2000W total
- Working temperature: -20°C ~ +70°C
- Relative humidity: 10% ~ 93% (non-condensing)
- Operating frequency: 50/60Hz
- Energy consumption: 0.02W
- Life time: 100,000 times
- Markings: CE, FC, RoHS
04
Dimensions
The module is secured with a screw fixing system.
- Module front: 50 mm x 50 mm
- Depth: 5 mm + 26 mm
- Body height: 49 mm
- Screw fixing spacing: 60 mm
05
Not Included
The module is supplied without a front panel or frame.
- Glass panel (not included)
- Metal frame (not included)
