Livolo

Livolo Touch Dimmer Light Switch Module – 2 Gang 2-Way / Intermediate – New Series VL-FC2SD2-2G

SKU: VL-FC2SD2-2G

AED 153

In stock

1
  • Delivery across all seven emirates. Free on orders over AED 750.
  • Order now, we confirm availability and delivery with you before you pay.

Livolo new-series 2 gang 2-way/intermediate touch dimmer module with faster response, wider bulb compatibility and low standby consumption.

Product details

The Livolo new-series 2 gang 2-way / intermediate touch dimmer light switch module is an improved, innovative product, the result of technology developed through years of study and research. It is a practical product, made from quality materials and built to last, bringing convenience and comfort to your home. It fits a round or square back box with 60mm screw spacing.

Improvements over the previous series:

  • → Compatible with more types of bulbs
  • → Faster response time when the touch panel is pressed
  • → More powerful, robust chip – made in Japan
  • → Reduced standby power consumption
  • → Compact design (smaller dimensions than the previous model)
  • → Maximum supported load of 2A per circuit

A maximum of 3 switches can be connected in the circuit (intermediate wiring)

Highlights

Livolo Touch Dimmer Light Switch Module – 2 Gang 2-Way / Intermediate – New Series VL-FC2SD2-2G – Livolo 2 Gang 2-Way / Intermediate Touch Dimmer Module
01

Livolo 2 Gang 2-Way / Intermediate Touch Dimmer Module

A double touch switch module with dimmer for 2-way (staircase) and intermediate circuits. Simple design, outstanding mechanism, available to pair with a variety of panel colours.

  • Please note: the image is for illustration only and the price does NOT include the Livolo glass panel, which must be purchased separately.
Livolo Touch Dimmer Light Switch Module – 2 Gang 2-Way / Intermediate – New Series VL-FC2SD2-2G – Dimmable Switch
02

Dimmable Switch

Press and hold the switch button to dim or brighten the lamp.

  • Some switches do not have the RF remote control function. Please order only switches that include this function if required.
Livolo Touch Dimmer Light Switch Module – 2 Gang 2-Way / Intermediate – New Series VL-FC2SD2-2G – Compatible / Incompatible Lamps
03

Compatible / Incompatible Lamps

  • Compatible: halogen lamps
  • Compatible: incandescent lamps
  • Compatible: dimmable LED lamps
  • Incompatible: energy-saving lamps
  • Incompatible: fluorescent lamps
  • Incompatible: standard (non-dimmable) LED lamps
Livolo Touch Dimmer Light Switch Module – 2 Gang 2-Way / Intermediate – New Series VL-FC2SD2-2G – Light Indicator
04

Light Indicator

Red and blue LEDs show whether the switch is on or off, making it easy to find in the dark. The LED lights up clearly and the switch gives a clear sound.

  • Red LED: switch is on
  • Blue LED: switch is off
  • MCU smart chip with built-in microchip technology
Livolo Touch Dimmer Light Switch Module – 2 Gang 2-Way / Intermediate – New Series VL-FC2SD2-2G – Improved New Series
05

Improved New Series

Unmatched performance with reduced energy consumption. The new series is an improved version of the previous model.

Livolo Touch Dimmer Light Switch Module – 2 Gang 2-Way / Intermediate – New Series VL-FC2SD2-2G – Design
06

Design

The elegant design stays intact and does not discolour.

07

Structure

The switch module fits with an elegant crystal glass panel and a metal frame, both sold separately.

  • Elegant crystal panel (not included)
  • Switch module (included)
  • Metal frame (not included)
  • Screw fixing system: 60 mm
08

Technical Data

  • Panel dimensions: 80 mm x 80 mm
  • Panel thickness: 4 mm
  • Module depth: 33 mm
  • Frame offset: 8 mm
  • Rated voltage: 100–240V~ 50/60Hz
  • Load: 2A/gang
  • Terminals: N/G, L2, L1, L, COM
09

Installation Instructions

Wiring diagram: connect neutral (N) to the lamps, phase (L) to the L terminal of both switches, the lamps to L1 and L2, and link the COM terminals of both switches for 2-way / intermediate operation.
