Livolo

Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module

SKU: C7-VL-FCMM10A-1W

AED 19

In stock

Colour: White
1
  • Delivery across all seven emirates. Free on orders over AED 750.
  • Order now, we confirm availability and delivery with you before you pay.

Livolo 1 gang mechanical intermediate (cross) switch module, fits round or square boxes with 60mm screw spacing and Livolo glass frames.

Product details

The Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module belongs to the new series – an improved, innovative product resulting from technology developed over years of study and research. It is a practical product, made from quality materials and built to last, bringing utility and comfort to your home. It mounts in a round or square wall box with 60mm spacing between the screws.

Improvements over the previous series:

  • → Compatibility with more types of bulbs
  • → Faster response time when the touch is activated
  • → More powerful and robust chip – made in Japan
  • → Reduced stand-by power consumption
  • → Compact design (smaller dimensions than the previous model)
  • → Maximum supported load of 5A / circuit

Compatible with glass frames for standard German wall boxes or Italian modular wall boxes.

Highlights

Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module – Livolo Single Mechanical Intermediate Switch Module
01

Livolo Single Mechanical Intermediate Switch Module

Part of a wide product range: simple design, outstanding mechanism. This single mechanical intermediate (cross) switch module is designed for multi-point light control alongside two-way switches.

  • Mechanical two-way switches only work when installed with other Livolo mechanical two-way or intermediate products
  • Livolo products do NOT work with other brands
  • The mechanical module can be used as a normal module or as a two-way module
  • The glass frame is sold separately
Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module – Does Not Discolour
02

Does Not Discolour

The elegant design stays intact.

Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module – Wiring Diagram: Two-Way – Intermediate
03

Wiring Diagram: Two-Way – Intermediate

The intermediate switch is fitted between two two-way switches to control one light from three points.

  • Phase (live) connects to the first two-way switch
  • Two traveller wires run from the first two-way switch to the intermediate switch
  • Two traveller wires run from the intermediate switch to the second two-way switch
  • The second two-way switch connects to the light bulb
  • Neutral connects directly to the light bulb
Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module – Structure
04

Structure

The switch assembly consists of a glass frame, the mechanical module and a metal frame.

  • Glass frame (not included)
  • Mechanical module
  • Metal frame (not included)
Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module – Dimensions
05

Dimensions

  • Screw fixing distance (vertical): 85 mm
  • Screw fixing distance (horizontal): 60 mm
  • Module width: 22.5 mm
  • Module height: 45 mm
  • Module depth: 36 mm
Livolo 1 Gang Mechanical Intermediate (Cross) Light Switch Module – Installation Steps
06

Installation Steps

  • 1. Open the package.
  • 2. Connect the wires and tighten the screws.
  • 3. Use the 2 screws to fix the frame.
  • 4. Fit the glass frame (click into place).
